Medium Duty Castors - Pressed Steel (101kg to 250kg Capacity)
Medium Duty Pressed Steel Castors have a load capacity between 101kg to 250kg Individual Castor Load Capacity.A castor's load capacity is usually the first criteria that needs to be identified. If you need to carry a total load (including the transport equipment) over 4 castors of between 300kg or and 750kg...>, these are the castors for you. You can read more about Recommended Load Capacity Considerations here.
Your next criteria is likely to be how you're going to attach the castors and there are two main choices. A rectangular Plate Fixing or a Single Bolt Hole Fitting.
Next comes the Castor and Wheels. Our medium duty pressed steel castors have complete. These include Nylon/Polypropylene, Blue Elastic Rubber Tyre, Polyurethane (both Injection Moulded or Bonded), Grey or Black Rubber Tyre, Cast Iron.
Some users have specific bearing requirements too. A Smooth Plain Bore is simply a smooth hole in the middle of the wheel and the lowest cost option. It's great if you're not carrying too much weight. Roller Bearing and Ball Bearings are available and these are necessary to lower the rolling resistance (the force needed to keep a wheel which is carrying weight moving) Read More
- Display 15 Products per page
In Stock125mm Swivel Castor, 150kg Capacity | Polyurethane Tyre Wheel, Roller Bearing (MSVH125PN1B)
£10.86125mm Swivel Castor (Pressed Steel) with a 12mm Si... Read Morengle Bolt Hole and a Red Polyurethane Tyred on a White Nylon Centred Wheel with a Roller Bearing. Load Capacity = 150kg using manual propulsion at 4km/h (walking speed).- In Stock
125mm Swivel Castor, 150kg Capacity | Polyurethane Tyre Wheel, Single Ball Bearing (MSVH125PN2B)
£14.70125mm Single Bolt Hole (12mm) Pressed Steel Swivel... Read More Castor. This castor has a Polyurethane Tyred Wheel on a Nylon Centred Wheel with a single Ball Bearing. The Load Capacity is 150kg using manual propulsion at 4km/h.Key Specifications:- Bolt Hole Size: 13mm (to suit an M12 bolt)
- Overall Height: 154mm
- Castor Offset: 40mm
- Wheel Material: Polyurethane tyre on a Nylon Centre
- Tyre Hardness: 92 (+/- 3) Shore A
- In Stock
125mm Swivel Castor, 150kg Capacity | Rubber Tyre Wheel, Ball Bearing (1321068)
£14.13125mm Top Plate Swivel Castor (Pressed Steel) w... Read Moreith 80x60 Hole Centres. Blue Rubber Tyre / Nylon Centre Wheel with Ball Bearing. Load Capacity = 150kg
This is a 4 hole plate fitting castor and the bolt holes suit an 8mm bolt as well as being slotted (rather than round) to accommodate 80/76mm x 60x44.5mm.
- Out of Stock - On the Way
125mm Swivel Castor, 150kg Capacity | Rubber Tyre Wheel, Ball Bearing (1321118)
£16.10125mm Bolt Hole Swivel Castor (Pressed Steel) with... Read More 10mm Bolt Hole. Blue Rubber Tyre / Nylon Centre Wheel with Ball Bearing. Load Capacity = 150kg - In Stock
125mm Swivel Castor, 150kg Capacity | Rubber Tyre Wheel, Roller Bearing (MSVH125RN1B)
£12.06125mm Single Bolt Hole (12mm) Swivel Castor (Press... Read Moreed Steel). Blue Elastic Rubber Tyre / Nylon Centred Wheel with Roller Bearing. Load Capacity = 150kg - In Stock
125mm Swivel Castor, 150kg Capacity | Rubber Tyre Wheel, Single Ball Bearing (MSVH125RN2B)
£16.51125mm Single Bolt Hole (12mm) Pressed Steel Swivel... Read More Castor. This castor has an Elastic Blue Rubber Tyred Wheel on a Nylon Centred Wheel with a Single Ball Bearing. The Load Capacity is 150kg using manual propulsion at 4km/h. - In Stock
125mm Swivel Castor, 160kg Capacity | Polypropylene Wheel, Plain Bore (LSV125PP)
£8.21125mm top Plate Swivel Castor with a White Polypro... Read Morepylene wheel. It has 80x60mm bolt hole centres and a load capacity of 160kg using manual propulsion at 4km/hThis is one of our most popular castors and the White Polypropylene wheel is non-marking and won’t damage concrete floors. Because it is a hard tread it has the lowest rolling and swivelling resistance. It is ideal as a new component or a replacement caster for most general purpose domestic or industrial castor where the travel speed of the castor generally does not exceed walking speed. - In Stock
125mm Swivel Castor, 180kg Capacity | Rubber Tyre Wheel, Plain Bore (561RN)
£34.53125mm Top Plate Swivel Castor (Pressed Steel) with... Read More 140x105 Hole Centres. Rubber Tyre / Nylon Centre Wheel with Plain Bore. Load Capacity = 180kg - In Stock
125mm Swivel Castor, 180kg Capacity | Rubber Tyre Wheel, Roller Bearing (522RNB)
£30.43125mm Top Plate Swivel Castor (Pressed Steel) with... Read More 80x60 Hole Centres. Blue Rubber Tyre / Nylon Centre Wheel with Roller Bearing. Load Capacity = 180kg - In Stock
125mm Swivel Castor, 180kg Capacity | Rubber Tyre Wheel, Roller Bearing (522RTB)
£39.32125mm Top Plate Swivel Castor (Flexello 22 Series ... Read MorePressed Steel) with 80x60mm Fixing Bolt Hole Centres. Black Rubber Tyre on a Cast Iron Centre Wheel with Roller Bearing. Load Capacity = 180kg - In Stock
125mm Swivel Castor, 180kg Capacity | Rubber Tyre Wheel, Roller Bearing (561RNB)
£35.96125mm Top Plate Swivel Castor (Pressed Steel) with... Read More 140x105mm Bolt Hole Centres. Blue Rubber Tyre / Nylon Centre Wheel with Roller Bearing. Load Capacity = 180kg - In Stock
125mm Swivel Castor, 200kg Capacity | Nylon Wheel, Ball Bearing (MSV125NY2B)
£13.72125mm White Nylon Wheel with a ball bearing fitted... Read More into a pressed steel swivel castor bracket. The Swivel Bracket has a 4 hole top plate with 80x60mm bolt hole spacing. The load capacity of this castor is 200kg using manual propulsion at 4km/h (walking speed)The Nylon Wheel is a hard wheel giving it a low tractive resistance which makes it it easier to get moving compared with softer rubber tread wheels. The strength of nylon and because it wont damage concrete floors makes it one of the most popular choices. The ball bearing lowers the rolling resistance to reduce the effort required to move the castors. Put this wheel into a strong bracket that has a double ball race in the swivel head makes this castor a great choice for the widest range of industrial and domestic applications. - In Stock
125mm Swivel Castor, 200kg Capacity | Nylon Wheel, Roller Bearing (MSV125NY1B)
£10.59125mm White Nylon Wheel with a roller bearing f... Read Moreitted into a pressed steel swivel castor bracket. The Swivel Bracket has a 4 hole top plate with 80x60mm bolt hole spacing. The load capacity of this castor is 200kg using manual propulsion at 4km/h (walking speed)
The Nylon Wheel is a hard wheel giving it a low tractive resistance which makes it it easier to get moving compared with softer rubber tread wheels. The strength of nylon and because it wont damage concrete floors makes it one of the most popular choices. The roller bearing lowers the rolling resistance to reduce the effort required to move the castors. Put this wheel into a strong bracket that has a double ball race in the swivel head makes this castor a great choice for the widest range of industrial and domestic applications.
- In Stock
125mm Swivel Castor, 200kg Capacity | Polyurethane Tyre Wheel, Ball Bearing (MSV125PN2B)
£16.84Swivel Castor (Pressed Steel) - 125mm... Read Moreong> Polyurethane Tyre with Nylon Centre Wheel (200kg Load Capacity)Engineered for durability and smooth performance, this Swivel Castor is built with a pressed steel frame and a red polyurethane tyre bonded to a white nylon centre. Designed to deliver exceptional manoeuvrability and low rolling resistance, it’s perfect for industrial trolleys, carts, and medium-duty applications.The swivel head features a double ball bearing race for effortless rotation and precise handling, while integral nylon thread guards protects the bearing from debris—ensuring long-lasting, reliable performance and smooth rolling.Key Features- Excellent Mobility: Double ball bearing race provides smooth 360° swivel action.
- Durable Construction: Pressed steel housing with high-quality polyurethane wheel.
- Low Rolling Resistance: Polyurethane-on-nylon wheel with a single ball bearing ensures quiet, efficient movement.
- Long Service Life: Thread guards prevent dirt ingress for extended bearing performance.
- High Load Capacity: Rated to support up to 200kg per castor.
- Top Plate Dimensions: 105×80mm
- Bolt Hole Centres: 80/77×60mm
- Bolt Hole Size: 9mm (fits 8mm fixing bolt)
- Overall Height: 155mm
- Castor Offset: 40mm
- Wheel Diameter: 125mm
- Wheel Tread Width: 35mm
- Wheel Material: Polyurethane (92 Shore A) on Nylon Centre
- Bearing Type: Single Ball Bearing
- In Stock
125mm Swivel Castor, 200kg Capacity | Polyurethane Tyre Wheel, Roller Bearing (MSV125PN1B)
£15.31125mm Top Plate Swivel Castor (Pressed Steel) with... Read More 80x60 Hole Centres. Polyurethane Tyre / Nylon Centre Wheel with Roller Bearing. Load Capacity = 200kg
