In Stock100mm AGV Swivel Castor, Twin Wheel, 310kg Load | Polyurethane Wheel, Ball bearing (GAAD100ASFHUD)
Original price was: £198.39.£192.61Current price is: £192.61. Sale!This Twin wheel 100mm Automated Guided Vehicle (AG ... Read MoreV) Castor has a bracket made from strong Forged steel that is zinc plated. There is a hardened Taper Roller Bearing in he swivel head, which has a grease nipple, for smooth swivelling action and durability. The castor is unique because it has a self-aligned function enabled by two swivelling axes each with different swivelling radii so that the castor's offset can automatically alter when changing direction to optimise the castor's turning circle for the AGV. Specifically, the offset can range from 10mm to 30mm which reduces the castors 'swing' enabling it to better follow the designated path. The Top Plate is 112mm x 112mm and has 4 bolt holes that are spaced 92mm x 92mm, each with a 9mm hole diameter, This castor frame has two wheels with a Polyurethane tyre (Shore A 95) on an Aluminium centre each containing ball bearings, The polyurethane wheel has excellent elasticity the minimises slipping that can happen when an AGV starts or stops. In addition, the elasticity also absorbs small shocks arising from small imperfections in the floor. The wheel itself is non marking and will not damage the floor. -
Out of Stock - On the Way100mm Braked Castor, 300kg Capacity | Polyurethane Tyre Wheel, Ball Bearing (461PABBR)
£42.28100mm Top Plate Swivel with Brake Castor with 105x ... Read More80mm Bolt Hole Centres. The Castor wheel has a Polyurethane Tyre (94 Shore A) on an Aluminium Centre with Ball Bearings. The Load Capacity is 300kg using manual propulsion at 4km/h. Key Specifications: Top Plate Size: 128x102mm Bolt Hole Centres: 100/105mm x 76/60mm Bolt Hole Size: 11.2mm (Suited to M10 Fixing Bolts) Overall Height: 125mm Castor Offset: 26mm Brake Style: Wheel Brake. When applied, the brake locks the castor wheel and the swivel head is still free to rotate Wheel Material: Polyurethane Tyre (94 Shore A) / Aluminium Centre Bearing Type: Ball Bearings -
In Stock100mm Fixed Castor | Polyurethane Tyre Wheel, Roller Bearing, 180kg Capacity (MFZ100PN1B)
£10.75100mm Red Polyurethane Tyre Wheel on a Nylon Centr ... Read Moree with a roller bearing fitted into a pressed steel Fixed castor bracket. The Fixed Bracket has a 4 hole top plate with 80x60mm bolt hole spacing. The load capacity of this castor is 180kg using manual propulsion at 4km/h (walking speed) The Polyurethane tyre offers a low tractive resistance making it easier to get moving compared with softer rubber tread wheels. It is also a bit softer than hard tread wheels making the castor smoother and quieter running. The polyurethane tyre is also non-marking and gentle on floors while the roller bearing lowers the rolling resistance to reduce the effort required to move the castors. Put this wheel into a strong bracket and you have a castor that is a great choice for the wide range of industrial and domestic applications. -
In Stock100mm Fixed Castor, 150kg Capacity | Polyurethane Tyre Wheel, Roller Bearing (1321986)
£11.09100mm Top Plate Fixed Castor (Pressed Steel) with ... Read More80x60mm Hole Centres and a Red Polyurethane Tyre on a Nylon Centre Wheel with Roller Bearing. Load Capacity = 150kg This is a 4 hole plate fitting castor and the bolt holes suit an 8mm bolt as well as being slotted (rather than round) to accommodate 80/76mm x 60x44.5mm. -
In Stock100mm Fixed Castor, 150kg Capacity | Polyurethane Tyre Wheel, Roller Bearing (MFK100PN1B)
£11.27100mm Top Plate Fixed Castor (Pressed Steel) with ... Read More80x60 Hole Centres. Polyurethane Tyre / Nylon Centre Wheel with Roller Bearing. Load Capacity = 150kg -
In Stock100mm Fixed Castor, 180kg Capacity | Polyurethane Tyre Wheel, Ball Bearing (MFZ100PN2B)
£12.36100mm Red Polyurethane Tyre Wheel on a Nylon Centr ... Read Moree with a ball bearing fitted into a pressed steel Fixed castor bracket. The Fixed Bracket has a 4 hole top plate with 80x60mm bolt hole spacing. The load capacity of this castor is 180kg using manual propulsion at 4km/h (walking speed) The Polyurethane tyre offers a low tractive resistance making it easier to get moving compared with softer rubber tread wheels. It is also a bit softer than hard tread wheels making the castor smoother and quieter running. The polyurethane tyre is also non-marking and gentle on floors while the ball bearing lowers the rolling resistance to reduce the effort required to move the castors. Put this wheel into a strong bracket and you have a castor that is a great choice for the wide range of industrial and domestic applications. -
In Stock100mm Fixed Castor, 220kg Capacity | Polyurethane Tyre Wheel, Plain Bore, (488PN)
£16.22100mm Top Plate Fixed Castor (Pressed Steel) with ... Read More100x48 Hole Centres. Polyurethane Tyre / Nylon Centre Wheel with Plain Bore. Load Capacity = 220kg -
In Stock100mm Fixed Castor, 225kg Capacity | Polyurethane Tyre Wheel, Plain Bore (TF4100PT04)
£32.48100mm Fixed Castor (REVVO Brand) with a Polyuretha ... Read Morene Tyre Wheel. The top plate measures 145x110mm top plate size and has 105X80mm Fixing Bolt Hole Centres. The wheel has a Polyurethane Tyre on a Cast Iron with a Smooth Plain Bore. Load Capacity = 250Kg -
In Stock
100mm Fixed Castor, 225kg Capacity | Polyurethane Tyre Wheel, Roller Bearing (TF4100PT14)
£44.40100mm Fixed Castor (REVVO Branded Pressed Steel) w ... Read Moreith a Polyurethane Tyre Wheel. The top plate measures 145x110mm top plate size and has 105X80mm Fixing Bolt Hole Centres. The wheel has a Polyurethane Tyre on a Cast Iron with a Needle Roller Bearing. Load Capacity = 225Kg Key Specifications: Top Plate Size: 145x110mm Bolt Hole Centres: 105x80mm / 116x635mm Overall Height: 139mm Wheel Material: Polyurethane Tyre on a Cast Iron Centre Bearing Type: Roller Bearing Load Rating: 225kg (hand pushed to 4km/h) -
In Stock100mm Fixed Castor, 250kg Capacity | Polyurethane Tyre Wheel, Plain Bore (429PN)
£19.55100mm Top Plate Fixed Castor (Flexello - Pressed S ... Read Moreteel) with 80x60 Hole Centres. Polyurethane Tyre / Nylon Centre Wheel with Plain Bore. Load Capacity = 250kg -
In Stock
100mm Fixed Castor, 250kg Capacity | Polyurethane Tyre Wheel, Roller Bearing (429PNB)
£19.38100mm Top Plate Fixed Castor (Flexello - Pressed S ... Read Moreteel) with 80x60mm Fixing Bolt Hole Centres. The wheel has a Polyurethane Tyre on a Nylon Centre with a Roller Bearing. The Load rating is 250kg using manual propulsion and 4km/h. -
In Stock100mm Fixed Castor, 250kg Capacity | Polyurethane Tyre Wheel, Roller Bearing (429SUB)
£40.25100mm Fixed Castor (Flexello Pressed Steel) with T ... Read Moreop Plate and 80x60mm Bolt Hole Centres. Red Polyurethane Tyre on a Red Painted Cast Iron Centre Wheel with Roller Bearing. Load Capacity = 250kg using manual propulsion at 4km/h. -
In Stock
100mm Fixed Castor, 250kg Capacity | Polyurethane Tyre Wheel, Roller Bearing, 10mm Bolt Hole (488PNB)
£21.68100mm Top Plate Fixed Castor (Pressed Steel) with ... Read More100x48 Hole Centres. Polyurethane Tyre / Nylon Centre Wheel with Roller Bearing. Load Capacity = 250kg -
In Stock100mm Fixed Castor, 295kg Capacity | Polyurethane Tyre Wheel, Roller Bearing (488SUB)
£39.06100mm Top Plate Pressed Steel Fixed Castor (Flexel ... Read Morelo Brand) with 100x48mm Hole Centres. The castor wheel has a Red Polyurethane Tyre on a red Painted Cast Iron Centre Wheel with 43mm Tread with and Needle Roller Bearing. Load Capacity = 295kg -
In Stock100mm Fixed Castor, 300kg Capacity | Polyurethane Tyre Wheel, Ball Bearing (488PAB)
£25.67100mm Top Plate Fixed Castor with 100x48mm Bolt Ho ... Read Morele Centres. The Wheel has a Polyurethane Tyre on an Aluminium Centre Wheel with Ball Bearings. The Load Capacity is 300kg using manual propulsion at 4km/h. Key Specifications: Top Plate Size: 121x80mm Bolt Hole Centres: 100x48mm Overall Height: 125mm Wheel Material: Polyurethane Tyre (94 Shore A) / Aluminium Centre Bearing Type: Ball Bearings
