In StockSwivel Castor (Twin Wheel), 300mm, 4000kg Capacity, Polyurethane Tyre Wheel, Ball Bearing (K2ST300PC2BD)
£911.75300mm Twin Wheel Extra Heavy Duty Swivel Castor wi... Read Moreth Directional Lock. The Castor Comes with 2 Heavy Duty Wheels with Polyurethane Tyres on a Cast Iron Centre. Each wheel runs on quality ball bearings. The load rating of this product is 4,000kg.The directional lock fixes the swivel head in one direction for straight line travel.- In Stock
100mm Fixed Castor, 300kg Capacity | Cast Iron Wheel, Roller Bearing (KFMG100CIB)
£24.95100mm Top Plate Fixed Castor (Fabricated Steel) wi... Read Moreth 105x80mm Bolt Hole Centres. The wheel is a solid Cast Iron Wheel with a Needle Roller Bearing. Load Capacity = 300kg using manual propulsion at 4km/h (walking speed).Fixed castors are often called Rigid castors because the bracket or frame has no moving partsKey Specifications and Features:- Top Plate Size: 140x110mm
- Bolt Hole Centres: Slotted 114x87mm / 97.5x71.5mm
- Fixing Bolt Size: 12mm
- Overall Height: 143mm
- Bearing Type: Roller Bearing
- Load Capacity: 300kg (manual propulsion at 4km/h)
- Cast iron castor wheels have a very hard tread making them the easiest of wheels to move (low tractive resistance). They have a very high load capacity, extremely wear resistant and not affected by swarf or aggressive materials.
- In Stock
Castor Wheel 100mm | Polyurethane Tyre / Cast Iron Centre, 300kg, 20mm Ball bearing (AW100PCB)
Original price was: £41.05.£25.29Current price is: £25.29.Sale!100mm Polyurethane Tyre on a Cast Iron Centre c... Read Moreaster wheel with 20mm Ball bearing, 40mm Tread Width and 40mm Hub Length (the distance through the central bore). The load capacity is 300kg using manual propulsion at 4km/h.
This wheel has ball bearing in the bore which greatly reduce the wheels rolling resistance and consequently the effort required to start rolling.
- In Stock
125mm Fabricated Steel Swivel Castor, 350kg Capacity | Polyurethane Tyre Wheel, Ball bearing (KSMG125CRPCB)
£55.12125mm Swivel Castor (Fabricated Steel) with 105x80... Read Moremm Fixing Bolt Hole Centres. The wheel has a Crown Tread Polyurethane Tyred on Cast Iron Centre Wheel with Ball Bearings. Load Capacity = 350kgKey Specifications and Features:- Top Plate Size: 140x110mm
- Bolt Hole Centres: Slotted 114x87mm / 97.5x71.5mm
- Fixing Bolt Size: 12mm
- Overall Height: 165mm
- Offset: 39mm
- Bearing Type: Ball Bearing
- Tread Hardness: 92 +/-3 Shore A
- Load Capacity: 350kg (manual propulsion at 4km/h)
- Crowned Polyurethane Tread for easy manoeuvrability.
- In Stock
150mm AGV Swivel Castor, Twin Wheel, 630kg Capacity | Polyurethane Wheel, Ball bearing (GASD150ASFHUD)
Original price was: £288.88.£280.22Current price is: £280.22.Sale!This Twin wheel ... Read MoreAutomated Guided Vehicle (AGV) Castor with 150m diameter wheels has shock absorbing function and a bracket made from strong Forged steel that is zinc plated. There is double thrust bearing in the swivel head to achieve a high load capacity and maintain castor performance and durability.The role of the spring in an AGV castor is different to that of a standard shock absorbing castor. In a standard shock absorbing castor, the spring absorbs shock and noise whereas, it's role in a AGV castor is primarily to keep the wheels in contact with the floor.When determining the overall height requirement of a shock absorbing AVG, it should be designed based on the spring cushion being fully compressed.The shock absorbing pad made from a special rubber compound absorbs minor shocks and vibrations to protect the AGV unit. There is a 10mm range of compression which helps prevent the castors from losing contact with the floor which may be caused by small floor imperfections. An AGV's castor leaving the floor when changing directions is often the cause of the AGV becoming unbalanced and coming to a stop by straying off its designated path.The Top Plate is 145mm x 145mm and has 4 bolt holes that are spaced 120mm x 120mm, each with a 11mm hole diameterThis castor frame has two wheels with a Polyurethane tyre (Shore A 95) on an Aluminium centre each containing ball bearings, Having a twin wheel castor is great for reducing the effort required to swivel the castor and most efficient by reducing the amount of room the castor needs to turn the AGV Cart.The polyurethane wheel has excellent elasticity the minimises slipping that can happen when an AGV starts or stops. In addition, the elasticity also absorbs small shocks arising from small imperfections in the floor. The wheel itself is non marking and will not damage the floor. - In Stock
100mm Swivel Castor, 160kg Capacity | Rubber Tyre Wheel, Ball Bearing (MSV100RN2B)
£10.50100mm Swivel Castor bracket (Pressed Steel) fitted... Read More with a Blue Elastic Rubber Tyre on a nylon centre wheel with a ball bearing. The Swivel Bracket has a 4 hole top plate with 80x60mm bolt hole spacing. The load capacity of this castor is 160kg using manual propulsion at 4km/h (walking speed)The Blue Elastic Rubber Tyre offers a higher load capacity than standard grey or black rubber tyres and is non-marking, gentle on floors and the rubber absorbs vibrations whilst in motion making this a low noise option. The ball bearing lowers the rolling resistance to reduce the effort required to move the castors. Together with the strong bracket that has a double ball race in the swivel head makes this castors a great performer and one of our most popular products.This castor is often used on flight cases as well as in many medical, industrial and domestic applications. - In Stock
100mm Heavy Duty Gate Castor , 110kg Capacity | Fixed Castor with Nylon Wheel (GCBF100NY)
£104.68100mm Gate Castor with 100mm Fixed Castor and Nylo... Read Moren Wheel. This gate castor has a black weatherproof finish for outdoor use. The bracket body is fabricated in heavy duty steel and the castor housing is zinc plated.The Telescopic Compression starts at 20kg of pressure and is fully compressed at 30kg with a maximum travel of 65mmThe side mounted plate has 12mm fixing bolt holes that are spaced 190mm apart and the mounted bracket will protrude 78mm from the gate it has been fitted to.Gate castors are important to support large doors or heavy sliding steel gates. Our gate castors are spring loaded and this self levelling spring incorporated into the gate castor copes with uneven floors and provides support for the door to alleviate some of the strain on the hinges. Furthermore, a suitable gate castor will prevent damage to your flooring caused by the door or gate dragging on the floor. - In Stock
Castor Wheel 100mm | Cast Iron, 250kg, 12mm Plain Bore (100CI04)
£10.85100mm Cast Iron Wheel (Revvo Brand) with 12mm P... Read Morelain Bore, 38mm Tread Width and 45mm Hub Length. Load Capacity = 250Kg.
These castor wheels are able to withstand high temperatures and combine strength and shock resistance with long life and economy, The have very low tractive resistance and are first choice where ease of movement is required. Cast Iron can cause floor wear and noise. Although protected by a clear lacquer finish, like all ferrous metals, they will eventually rust.
The Revvo CI Series cast iron wheels are close grained casting of grey iron material sometimes described as semi-steel.
- In Stock
Ball Transfer Unit, 25.4mm Stainless Steel Load Ball, Flange 3 Hole Type, 60kg Load Capacity (K25BTUFL3SS)
£15.3025.4mm Ball Transfer Unit (Stainless Steel). 3 fix... Read Moreing hole (55.6mm spacing) flanged "Flying Saucer" model with Stainless Steel load ball and minor balls and a 40mm Seating Hole. This product is made from strong stainless steel and has a high load capacity of 60kg. Check 2D Image for Dimensional Data. - In Stock
200mm Swivel Castor with Brake, 205kg Capacity | Rubber Tyre Wheel, Roller Bearing (LSV200RMBBR)
£27.13200mm Top Plate Swivel and Brake Castor with a Bla... Read Moreck Rubber Tyre Wheel on a Pressed Steel centre complete with Thread Guards. It has 105x80mm bolt hole centres, an overall height of 235mm and a load capacity of 205kg using manual propulsion at 4km/h.This popular general purpose castor is fitted with a Black Rubber Tyre Wheel that is gentle on floors. The Caster wheel has a roller bearing that offers low rolling resistance. It is ideal as a new or replacement castor for most domestic or industrial applications such as a trolley or dolly where the travel speed of the castor generally does not exceed walking speed. - In Stock
200mm Flexello Polyurethane Tyre Wheel, 20mm Roller Bearing, 650kg (WPN8KRB20)
£38.69200mm Castor Wheel with Red Polyurethane Tyre on a... Read More White Nylon centre. 50mm Tread Width, 58mm Hub Length and 20mm Roller Bearing. Load Capacity = 650Kg - In Stock
150mm Fixed Castor, 400kg Capacity | Rubber Tyre Wheel, Ball Bearing (KFMG150RUB)
£45.46150mm Top Plate Fixed Castor (Fabricated Steel) wi... Read Moreth 105x80 Hole Centres. Rubber Tyre / Cast Iron Centre Wheel with Ball Bearing. Load Capacity = 400kg - In Stock
150mm Swivel Castor, 600kg Capacity | Polyurethane Tyre Wheel, Ball Bearing (BS5150PC2BA)
£112.08150mm Bolt Hole Swivel Castor (Fabricated Steel) w... Read Moreith 19.8mm Single Bolt Hole (to suit a 3/4" fixing Bolt). This is an extra heavy duty single bolt hole castor and the wheel has a Polyurethane Tyre wheel on a Cast Iron Centre with 50mm Tread width and Ball Bearing fitted. The Load Capacity is 600kg at 4km/h (walking speed) using manual propulsion.Key Specifications:- Ball Bearing Swivel Head
- Wheel Bearing Type: Ball Bearing
- Overall Height: 200mm
- Tread Width: 50mm
- Offset: 44.5mm
- Fixing Bolt Hole Size: 19.8mm
- Zinc Plated
- Load Capacity: 600kg using manual propulsion at km/h (walking speed)
- In Stock
50mm Low Level Swivel Castor, 270kg Capacity | Steel Wheel, Plain Bore (2SL050ST0L)
£28.7650mm Low Level Twin Wheel Swivel Castor (Revvo Bra... Read Morend). The steel wheels each have a tread width of 14mm and turn on a smooth Plain Bore. The Load Capacity of 270kg.This castors offers an exceptional load capacity in relation to their low overall working height and is ideal for heavy equipment being used on smooth, hard flooring. The differential action from the twin wheels makes for smooth operation.This castor has a round top plate with a diameter of 95mm and 4 fixing holes to suit a 6mm bolt. Each fixing hole is spaced 51mm from the directly opposite fixing hole (the largest distance between the fixing holes) - In Stock
Puncture Proof Wheel 260mm | Puncture Proof Tyre / Red Polypropylene Centre, 120kg, 25.4mm Plain Bore (PP260RP1D)
£39.64260mm Puncture Proof Wheel (Micro-Cellular Polyure... Read Morethane) with a Diamond Tread on a Red Polypropylene Centre. This Wheel has a 25.4mm Plain Bore, 85mm Tread Width, 76mm Hub Length, and 120kg Load Capacity
