In Stock125mm Swivel Castor, 250kg Capacity | Nylon Wheel, Ball Bearing (522NYBJ)
£29.09125mm Top Plate Swivel Castor (Pressed Steel) with... Read More 80x60mm Bolt Hole Centres (suit an 8mm Fixing Bolt). Nylon Wheel with Ball Bearing. Load Capacity = 250kg- In Stock
100mm Swivel Castor with Brake, 300kg Capacity | Polyurethane Tyre Wheel, Ball bearing (MSW100APCBBR)
Original price was: £39.81.£21.90Current price is: £21.90.Sale!100mm Top Plate Swivel Castor with Side Mounted Wh... Read Moreeel Brake. The housing is made with an extra strong fabricated (welded) bracket and the top plate has 4 fixing holes with 105x80mm bolt hole centres. The wheel is a Polyurethane Tyre / Cast Iron Centre Wheel running on two Ball Bearings for exceptional rolling performance. This castor has a Load Capacity of 300kg using manual propulsion at 4 km/h (walking speed).Key Specifications- Top Plate Dimensions: 135x110mm
- Bolt Hole Centres: 105x80/75mm
- Overall Height: 146mm
- Offset: 30mm +/- 2mm
- Wheel Material: Polyurethane Tyre on a Cast Iron Centre
- Tread Width: 40mm
- Bearing Type: Ball Bearings
- Brake Style: Wheel Brake: When applied, the wheel is locked but the swivel head can freely rotate.
- In Stock
Castor Wheel 100mm | Nylon, 300kg, 15mm Ball bearing (AW100NYBJ40)
£11.87100mm White Nylon Castor Wheel with 15mm Ball Jour... Read Morenal, 40mm Tread width and 40mm Hub Length (the distance through the central bore). This wheel is rated to 300kg - In Stock
Steel Wheel Tube: 12mm OD x 8mm ID x 46mm Length (2731-0042)
£1.32Steel wheel tube to reduce a 12mm bore to 8mm. Thi... Read Mores steel tube has a 12mm Outside Diameter x 8.2mm Inside Diameter and is 46mm Long to suits an M8 bolt.The tube is to suit a castor wheel with a 12mm bore and 45mm hub length. - In Stock
100mm High Temperature Swivel Castor With Brake, 125kg Capacity | Phenolic Resin Wheel, Plain Bore (MSX100HTBHBR)
£20.58100mm Single Bolt Hole Swivel Castor (Pressed Stee... Read Morel) with Swivel & Wheel Brake. High Temperature Phenolic Wheel (Plain Bore) - Rated to +280 degrees C. Load Capacity = 125kg - In Stock
75mm Swivel Castor, 50kg Capacity | Rubber Tyre Wheel, Plain Bore (LSV075RP)
£3.5075mm Grey Rubber Tyre Wheel on a Nylon centre fitt... Read Moreed into a Top Plate Swivel Castor with 55x42mm bolt hole centres. The load capacity of this castor is 50kg using manual propulsion at 4km/h.This popular general, light duty general purpose castor is fitted with a grey rubber tyre that is non-marking and gentle on floors. This castor is ideal for most domestic or industrial castor uses where a small yet sturdy swivel castor in needed. - In Stock
100mm Fixed Castor, 150kg Capacity | Polyurethane Tyre Wheel, Roller Bearing (MFK100PN1B)
£10.94100mm Top Plate Fixed Castor (Pressed Steel) with ... Read More80x60 Hole Centres. Polyurethane Tyre / Nylon Centre Wheel with Roller Bearing. Load Capacity = 150kg - In Stock
Castor Wheel, 150mm | V Grooved Cast Iron, 1000kg Capacity, 20mm Ball Bearing (150CV2H)
£66.95150mm V-Groove Cast Iron Wheel (Genuine Revvo bran... Read Mored) with a clear resin shellac finish and a 20mm Ball Bearing. The wheel's load capacity is 1,000kg and is ideal for use on inverted angle iron rail. - In Stock
50mm Footmaster Levelling Castor, 250kg Capacity | Nylon Wheel (KGDR-60S)
£46.47M12 x 18mm Threaded Stem Fitting Foot Master Le... Read Morevelling Castor with an ivory coloured powder coating finish. This product has a black Nylon Wheel with a 25mm Tread width, Die Cast Aluminium Foot Pad with a vibration damping rubber pad. This foot pad has a Retractable Ratchet operation.
.
Because of the lifting and lowering function of the Foot Master castor, like all Jacking Castors, it is important understand that each castor may be subjected to HALF THE TOTAL WEIGHT. Therefore, the recommended load capacity for each Foot Master Levelling Castor is half the castor's Static Load Capacity, that is, when the castors' levelling function is not being used. The load capacity of the Footmaster Castor when it is being moved and positioned is given by the Dynamic Load Capacity.
This levelling castor is a multi-functional swivel castor that provides mobility, levelling and anti-vibration functions. This allows users to move and position large equipment into place with added stability using the levelling and anti-vibration features.
- In Stock
200mm Swivel Castor with Brake, 535kg Capacity | Rubber Tyre Wheel, Roller Bearing (TSH200RU15F)
£139.49200mm Heavy Duty Top Plate Swivel Castor With S... Read Morewivel & Wheel Brake (Fabricated Castor) with 105x80 Hole Centres. Rubber Tyre / Cast Iron Centre Wheel with Roller Bearing. Load Capacity = 535kg
Features of the H Series Castor
- The Genuine Revvo H Series castor is made from heavy gauge forged steel with a hardened ball race in the swivel race that serve as both thrust and radial bearings.
- The swivel head comes with a metal swivel seal and hydraulic grease nipple
- The closed base of the swivel ring prevents downward escape of lubricant
- The side plates are press formed to a cylindrical shape to give the best strength to weight ratio
- In Stock
150mm Swivel Castor, 1500kg Capacity | Polyurethane Tyre Wheel, Ball bearing (GXT150ASFHUD)
Original price was: £476.39.£299.19Current price is: £299.19.Sale!150mm Polyure... Read Morethane tyre Wheel with an aluminium centre fitted into an extra strong Fabricated Top Plate Swivel Castor with 148/132x111/99mm bolt hole centres. The slotted bolt holes incorporate the European and UK standard 140x105mm bolt holes. The load capacity of this castor is 1500kg at 4km/h
This high performance castor is fitted with a quality polyurethane tyre wheel that will not mark the floor. An extra strong welded castor frame that is powder coated and fitted with a high performance castor wheel containing two ball bearings that turns on a specially designed integrated axle shaft arrangement makes this castor one of the most durable in the market. Perfect for moving very heavy loads where strength, durability and performance are critical
The swivel head of the 125mm - 250mm sizes of the GXT range come with a thrust bearing and a taper roller bearing in the swivel head.
- Out of Stock - On the Way
150mm Stainless Steel Swivel Castor With Brake, 200kg Capacity | Nylon Wheel, Plain Bore (MSS150NYBHBR)
£44.55150mm Bolt Hole Swivel Castor With Brake (Stainles... Read Mores Steel Castor) with 12mm Bolt Hole. Nylon Wheel with Plain Bore. Load Capacity = 200kg - Out of Stock - On the Way
300mm Swivel Castor, 680kg Capacity | Rubber Tyre Wheel, Ball bearing (HKS30025341)
£165.39300mm Top Plate Swivel Castor (Fabricated Steel) w... Read Moreith 105x80 Hole Centres. Rubber Tyre / Cast Iron Centre Wheel with Ball bearing. Load Capacity = 680kg - In Stock
Ball Transfer Unit, 30mm Spring Clip (K30BTUSPRCLP)
£0.8330mm Spring Clip to suit Drop-In Ball Unit with load ball size 30mm - Out of Stock - On the Way
150mm Fixed Castor, 500kg Capacity | Nylon Wheel, Roller Bearing (629NYB)
£32.50150mm Top Plate Fixed Castor (Pressed Steel) with ... Read More105x80 Hole Centres. Nylon Wheel with Roller Bearing. Load Capacity = 500kg
