Braked Castors
Braked Castors are sometimes referred to as lockable castors and it is usually swivel castors that have brakes. The Brake can lock either the wheel (Wheel Brake), the swivel head (Directional Lock), or both simultaneously (Total Stop or Swivel & Wheel Brake). It is un...common to find a fixed castor with a brake. Our GD Series of shock absorbing castors is one of the few that do. See GDS Shock Absorbing Castors here.Braked Castors can swivel the wheel 360 degrees about the vertical axis. They consist of a housing with a lockable brake and a caster wheel. The housing itself is made up of a plate fitting, swivel bearings and a yoke. The Yoke is often referred to as the castor’s frame or bracket.
The plate fitting determines how the castor is going to be attached to the equipment. It is usually either a single bolt hole fitting or a plate fixing which is generally square, rectangular or triangular. Plate fittings are usually bolted to equipment so knowing your required bolt hole centres is important. The Swivel Head consists of a ball race and a number of ball bearings that roll within it. Braked Castors, like Swivel Castors, can either have a single ball race or a double ball race. They perform the same function. The double ball race was developed for medium and heavy applications. This is because they are compact, perform well under static and dynamic loads and provide excellent steerability.
Braked Castor Offset
The Braked Castor’s offset it the distance from the swivel axis to the centre of the wheel (where it is secured to the castor frame). It is the reason any swivelling castor will go in the direction you want it to go regardless its starting direction. Read More
- Display 15 Products per page
In Stock100mm Swivel Castor with Brake, 250kg Capacity | Polyurethane Tyre Wheel, Plain Bore (422PNTSB)
£28.31100mm Top Plate Swivel Castor and Swivel & Whe... Read Moreel Brake (Pressed Steel) with 80x60mm Fixing Hole Centres. Polyurethane Tyre on a Nylon Centre Wheel with a Smooth Plain Bore. Load Capacity = 250kg.- Out of Stock - On the Way
150mm Swivel Castor with Brake, 500kg Capacity | Polyurethane Tyre Wheel, Ball Bearing (KBMG150PCB)
£67.96150mm Top Plate Swivel Castor With Brake (Fabricat... Read Moreed Steel) with a Polyurethane Tyre wheel with a Cast Iron Centre and Ball Bearings. Load Capacity = 500kg using manual propulsion at 4km/h.Key Specifications:- Brake Style: Swivel & Wheel brake (Total Stop Brake) which locks both the wheel and the swivel rotation
- Double Pedal Brake
- Top Plate Size: 140mm x 110mm
- Bolt Hole Centres: Slotted to 114x87mm / 97.5x71.5mm
- Overall Height: 190mm
- Tread Width: 45mm
- In Stock
Swivel Castor With Brake (Twin Wheel), 200mm, 2000kg Capacity, Polyurethane Tyre Wheel, Ball Bearing (K2BT200PC2B)
£477.18200mm Twin Wheel Extra Heavy Duty Fabricated Swive... Read Morel Castor with Brake. The swivel head turns on Thrust and Taper Roller Bearings for extra strength and the bracket is finished in Black Epoxy Paint.The Braking Mechanism on this product is a Wheel Brake only. This means that when the brake is applied it acts only on the castor wheels while the castor's swivel head is free to turn.This Castor has a Top Plate measuring 200mm X 200mm with Fixing Bolt Hole spacings of 160mm X 160mm drilled to 13mm diameter. The two Polyurethane Tyre on a Cast Iron Centre wheels each have Ball Bearings fitted to reduce the rolling resistance.The castor has s 2,000kg load rating at 4km/h - In Stock
80mm Swivel Castor with Brake, 130kg Capacity | Polyurethane Tyre Wheel, Roller Bearing (MSV080PN1BSWB)
£10.5680mm Red Polyurethane Tyre Wheel on a Nylon Cen... Read Morettre with a roller bearing fitted into a pressed steel swivel and brake castor bracket. The Swivel Brake Bracket has a 4 hole top plate with 80x60mm bolt hole spacing. The load capacity of this castor is 130kg using manual propulsion at 4km/h (walking speed)
The Polyurethane tyre offers a low tractive resistance making it easier to get moving compared with softer rubber tread wheels. It is also a bit softer than hard tread wheels making the castor smoother and quieter running. The polyurethane tyre is also non-marking and gentle on floors while the roller bearing lowers the rolling resistance to reduce the effort required to move the castors. Put this wheel into a strong bracket that has a double ball race in the swivel head and you have a castor that is a great choice for the wide range of industrial and domestic applications.
- In Stock
100mm Swivel and Brake Castor, 150kg Capacity | Rubber Tyre Wheel, Roller Bearing (MSVH100RN1BSWB)
£11.97100mm Single Bolt Hole (12mm) Swivel Castor with S... Read Morewivel and Wheel Brake (Pressed Steel). Blue Rubber Tyred / Nylon Centred Wheel with Roller Bearing. Load Capacity = 150kg - In Stock
125mm Swivel Castor with Brake, 250kg Capacity | Polyurethane Tyre Wheel, Roller Bearing (522SUBTSB)
£53.56125mm Top Plate Swivel Castor and Swivel & Whe... Read Moreel Brake (Flexello - Pressed Steel) with 80x60 Hole Centres. The wheel has a Polyurethane Tyre on a Cast Iron Centre Wheel complete with Roller Bearing. Load Capacity = 250kg - In Stock
200mm Swivel Castor with Brake, 400kg Capacity | Rubber Tyre Wheel, Ball Bearing (MSK200RN2BBR)
£44.26200mm Top Plate Swivel Castor with Brake (Pressed ... Read MoreSteel) with 105x80mm Fixing Bolt Hole Centres. Blue Elastic Rubber Tyre on a Black Nylon Centre Wheel with Ball Bearings. Load Capacity = 400kg.This castor has a heavy gauged pressed steel housing. With a 5mm thick Top Plate and 4mm thick forks, it is a castor built to last and suitable for arduous applications.Elastic Rubber Tyres have a soft tread and are both gentle on floors and non-marking. They are an excellent choice when a rubber tyre is needed and the weight to be carried is more than what a castor with a standard rubber tyre can hold. - Out of Stock - On the Way
125mm Stainless Steel Swivel Castor with Brake, 600kg Capacity | Nylon Wheel, Plain Bore (33661FR)
£177.07125mm Heavy Duty Top Plate Swivel Castor with Tota... Read Morel Stop Brake, nylon wheel with a 600kg load capacity. The top plate and frames are made from AISI 304 Stainless Steel Castor and the Stainless Steel balls from AISI 420. This castor has a 172mm overall height.Upgrade your equipment with our 125mm Heavy Duty Stainless Steel Swivel Brake Castor, designed for superior performance in demanding environments. Ideal for both industrial and domestic applications, this castor is built to resist corrosion and heavy use. The swivel head includes a double ball race with a hardened ball race track, ensuring smooth and reliable movement.Key Features:- Load Capacity: Supports up to 600kg, making it ideal for heavy loads.
- Top Plate Dimensions: Measures 135x110mm, with fixing bolt hole centres at 105x80mm and accommodates 12mm bolts for easy installation.
- Wheel Material: The castor features a white nylon (polyamide) wheel with a 45mm tread width, designed to provide non-marking performance.
- Total Stop Brake (Swivel & Wheel Brake): Brakes both the wheel and the swivel rotation
- In Stock
200mm Swivel Castor With Brake, 6000kg Capacity | Machine Cast Nylon Wheel, Ball bearing (UGXT200BSFMCQ)
Original price was: £1,387.38.£871.30Current price is: £871.30.Sale!200mm Machine Ca... Read Morest Nylon Wheel fitted into an extra strong Fabricated Top Plate Swivel and Wheel Brake Castor with a grease nipple in the swivel head. The bolt holes centres are 210x160mm bolt hole centres and the load capacity is 6,000kg. This castor is Power Towable to 4km/hThis super heavy duty high performance castor is fitted with a white machine cast nylon wheel that will not mark the floor. An extra strong welded castor frame that is powder coated and fitted with a high performance castor wheel containing two ball bearings that turns on a specially designed integrated axle shaft arrangement makes this castor one of the most durable in the market. Perfect for moving very heavy loads where strength, durability and performance are critical - In Stock
100mm Swivel Castor with Brake, 150kg Capacity | Nylon Wheel, Ball Bearing (MSV100NY2BSWB)
£10.96100mm White Nylon Wheel with a ball bearing fitted... Read More into a pressed steel swivel and brake castor bracket. The Swivel Brake Bracket has a 4 hole top plate with 80x60mm bolt hole spacing. The load capacity of this castor is 150kg using manual propulsion at 4km/h (walking speed)The Nylon Wheel has a low tractive resistance making it easier to get moving compared with softer rubber tread wheels. Together with the strength of nylon and because it wont damage concrete floors, makes nylon wheel castors probably the most popular choice.The ball bearing lowers the rolling resistance to reduce the effort required to move the castors. Put this wheel into a strong bracket that has a double ball race in the swivel head makes this castor a great choice for the widest range of industrial and domestic applications. - In Stock
200mm Swivel Castor with Brake (Powder Coated), 900kg Capacity | Polyurethane Tyre Wheel (KGHP200BSFMUD)
Original price was: £192.50.£111.60Current price is: £111.60.Sale!200mm Heavy-duty Swivel & Wheel Brake Castor w... Read Moreith a Powder Coated Pressed Steel Bracket and a 250mm overall height. The caster wheel has a Blue Polyurethane Tyre (Shore A 95) on an Aluminium Centre with Ball BearingsFeatures:- 900kg Load Capacity: For the most demanding applications and heavy-duty loads.
- Silver/Grey Powder Coating: Making this the best looking heavy-duty industrial castor on the market. The powder-coating not only looks great but also provides corrosion protection which prolongs its optimal performance and keeps the castor looking good.
- Total Stop Brake System: Applying the brake pedal simultaneously locks both the wheel and the swivel rotation.
- Quality Ball Bearings: For the lowest rolling resistance to reduce the effort needed to move.
- Double Ball Bearing Race and hardened bearing Seats in the swivel head: For an optimum swivel rotation function and durability.
- Strong Pressed Steel Plate: The top plate measure 140x110mm with fixing bolt holes slotted to 105x80/75mm to suit 10mm bolts
- Precision Engineered: These castors have an incredibly smooth swivelling function with no "rock" to the swivel head and no sideways movement on the wheel for exceptional operating performance.
- In Stock
200mm Swivel Castor with Brake, 2000kg Capacity | Polyurethane Tyre Wheel, Ball bearing (GXT200BSFHUD)
Original price was: £665.08.£417.69Current price is: £417.69.Sale!200mm Polyuretha... Read Morene tyre Wheel with an aluminium centre fitted into an extra strong Fabricated Top Plate Swivel Castor with wheel brake and 148/132x111/99mm bolt hole centres. The slotted bolt holes cover the European and UK standard 140x105mm bolt holes. The load capacity of this castor is 2000kg at 4km/hThis high performance castor is fitted with a quality polyurethane tyre wheel that will not mark the floor. An extra strong welded castor frame that is powder coated and fitted with a high performance castor wheel containing two ball bearings that turns on a specially designed integrated axle shaft arrangement makes this castor one of the most durable in the market. Perfect for moving very heavy loads where strength, durability and performance are criticalThe swivel head of the 125mm - 250mm sizes of the GXT range come with a thrust bearing and a taper roller bearing in the swivel head. - In Stock
200mm Swivel Castor with Brake, 500kg Capacity | Nylon Wheel (MSK200NYBR)
£33.65200mm Top Plate Swivel Castor with Brake (Pressed ... Read MoreSteel) with 105x80mm Bolt Hole Centres. White Nylon Wheel with a Smooth Plain bore. Load Capacity = 500kg.This castor has a heavy gauged pressed steel housing. With a 5mm thick Top Plate and 4mm thick forks, it is a castor built to last and suitable for arduous applications. - Out of Stock - On the Way
150mm Swivel Castor with Brake, 520kg Capacity | Nylon Wheel, Plain Bore (655NYSWB)
£86.92150mm Flexello Top Plate Swivel Castor and Swiv... Read Moreel & Wheel Brake (Heavy Duty Pressed Steel) with 140x105mm Bolt Hole Centres. Nylon Wheel with Plain Bore. Load Capacity = 520kg
The 55 series castor is made from heavy duty pressed steel with a bright zinc finish and roller ball bearing in the swivel head.
