Braked Castors
Braked Castors are sometimes referred to as lockable castors and it is usually swivel castors that have brakes. The Brake can lock either the wheel (Wheel Brake), the swivel head (Directional Lock), or both simultaneously (Total Stop or Swivel & Wheel Brake). It is un...common to find a fixed castor with a brake. Our GD Series of shock absorbing castors is one of the few that do. See GDS Shock Absorbing Castors here.Braked Castors can swivel the wheel 360 degrees about the vertical axis. They consist of a housing with a lockable brake and a caster wheel. The housing itself is made up of a plate fitting, swivel bearings and a yoke. The Yoke is often referred to as the castor’s frame or bracket.
The plate fitting determines how the castor is going to be attached to the equipment. It is usually either a single bolt hole fitting or a plate fixing which is generally square, rectangular or triangular. Plate fittings are usually bolted to equipment so knowing your required bolt hole centres is important. The Swivel Head consists of a ball race and a number of ball bearings that roll within it. Braked Castors, like Swivel Castors, can either have a single ball race or a double ball race. They perform the same function. The double ball race was developed for medium and heavy applications. This is because they are compact, perform well under static and dynamic loads and provide excellent steerability.
Braked Castor Offset
The Braked Castor’s offset it the distance from the swivel axis to the centre of the wheel (where it is secured to the castor frame). It is the reason any swivelling castor will go in the direction you want it to go regardless its starting direction. Read More
- Display 15 Products per page
In Stock80mm Swivel Castor with Brake, 130kg Capacity | Polyurethane Tyre Wheel, Roller Bearing (MSV080PN1BSWB)
£10.5680mm Red Polyurethane Tyre Wheel on a Nylon Centre... Read More with a roller bearing fitted into a pressed steel swivel and brake castor bracket. The Swivel Brake Bracket has a 4 hole top plate with 80x60mm bolt hole spacing. The load capacity of this castor is 130kg using manual propulsion at 4km/h (walking speed)Key Specifications:- Top Plate Size: 105x80mm
- Bolt Hole Centre: 80/77x60mm
- Bolt Hole Size: 9mm (to suit 8mm fixing bolts)
- Overall Height: 105mm
- Castor Offset: 40mm
- Swivel Radius: 127mm
- Bearing Type: Roller Bearing
- Brake Style: Swivel & Wheel Brake (also known as a Total Stop Brake because both the swivel action and wheel are locked when the brake is applied)
- Wheel Material: Red Polyurethane Tyre on Grey Nylon Centre
- Shore Hardness: 95A
