In Stock200mm Shock Absorbing Fixed Castor, 450kg Capacity | Polyurethane Tyre Wheel, Ball bearing (KGDSP200ARFMUD)
Original price was: £122.49.£65.09Current price is: £65.09.Sale!200mm Shock absorbing (15mm Compression) fixed ... Read Morecastor and Polyurethane Tyred Aluminium Wheel. Load Capacity = 450kg
For the compression performance, please see the image for the curve by clicking on the thumbnail image above. To use this curve, please calculate the weight being carried by this castor and divide that by the one less than the number of castors on your equipment, So if you have a trolley using 4 of these castors and the total weight being carried is 500kg, then the compression of the rubber pad is the reading given on the y axis at 167kg which is just over 10mm.
- Out of Stock - On the Way
80mm Swivel Castor, 130kg Capacity | Rubber Tyre Wheel, Roller Bearing (MSV080RN1B)
£8.7980mm Blue Elastic Rubber Tyre (65 Shore A) wheel o... Read Moren a nylon centre with a roller bearing fitted into a pressed steel swivel castor bracket. The Swivel Bracket has a 4 hole top plate with 80x60mm bolt hole spacing. The load capacity of this castor is 130kg using manual propulsion at 4km/h (walking speed)Key Specifications:- Top Plate Size: 105x80mm
- Bolt Hole Centre: 80/77x60mm
- Bolt Hole Size: 9mm (to suit 8mm fixing bolts)
- Overall Height: 105mm
- Castor Offset: 40mm
- Swivel Radius: 90mm
- Bearing Type: Roller Bearing
- Wheel Material: Blue Elastic Rubber Tyre on Black Nylon Centre
- Shore Hardness: 65A
- In Stock
125mm Swivel Castor with Brake, 85kg Capacity, | Rubber Tyre wheel, Ball Bearing (1322053)
£17.99125mm Top Plate Swivel Castor and Swivel & Whe... Read Moreel Brake (Pressed Steel) with 80x60 Hole Centres. Grey Rubber Tyre / Nylon Centre Wheel with Ball Bearing. Load Capacity = 85kgThis is a 4 hole plate fitting castor and the bolt holes suit an 8mm bolt as well as being slotted (rather than round) to accommodate 80/76mm x 60x44.5mm. - In Stock
Threaded Inset, Round, M12 | Suits 1 1/2″ Outside Diameter Tube with 14 Gauge Wall Thickness (RNDM125761)
£0.93Round Insert with M12 Thread for Round tube with D... Read Moreiameter (to the outside of the tube) of 1 1/2" and wall thickness of 14g (2.03mm) - In Stock
Castor Wheel 125mm | Phenolic Resin, 200kg, 15mm (AW125HT)
£34.17125mm Phenolic Resin High Temperature Wheel with o... Read Moreperating temperatures of between -40 Deg C to +280 Degree Celsius. It has a 15mm Plain Bore With 48mm Hub Length 200Kg Load Capacity - In Stock
100mm Fixed Castor, 300kg Capacity | Polyurethane Tyre Wheel, Ball bearing, (KF100NPSBJ300)
£21.53100mm Top Plate Fixed Castor (Pressed Steel). 80x6... Read More0 Bolt Hole Centres. Soft Blue Polyurethane Tyre (Shore A 80) on a Black Nylon Centre. The wheel has two quality ball bearing and the load capacity of this castor is 300kg at 4km/h (walking speed) - In Stock
63mm Swivel Castor, 60kg Capacity | 63mm Rubber Tyre Wheel, Plain Bore (261RN)
£8.8063mm Swivel Castor (Pressed Steel) with 4-hole top... Read More plate and 76x44.5mm Fixing Bolt Hole Centres and an overall height of 81mm. The wheel has a Blue Elastic Rubber Tyre with a black Nylon Centre, 25mm Tread Width and a smooth Plain Bore. Load Capacity = 60kg.Elastic Blue Rubber tyres are stronger than standard natural rubber. It has a soft tread and is both gentle on floors and non-marking while absorbing fine vibrations when moving which provides user comfort and limits noise. - In Stock
125mm Fixed Castor, 300kg Capacity | Polyurethane Tyre Wheel, Ball Bearing (MFK125PC2B)
Original price was: £61.85.£36.06Current price is: £36.06.Sale!125mm Top Plate Fixed Castor (Pressed Steel) with ... Read More80x60mm Fixing Bolt Hole Centres. Polyurethane Tyre on a Cast Iron Centre Wheel with a 40mm Tread Width and Ball Bearings. Load Capacity = 300kg.This castor is made from 4mm thick heavy gauge pressed steel. It is a product that is built to last and is great for arduous applications.The polyurethane elastomer wheel offers excellent elasticity, hardness and resistance to compression. This means that while it has a low rolling resistance it is also gentle on floors and absorbs some of the rolling vibration for user comfort and reduced noise. - In Stock
Swivel Castor, 250mm, 615kg Capacity, Rubber Tyre Wheel, Ball Bearing, (HKS25025341)
£156.81250mm Top Plate Swivel Castor (Fabricated Steel)... Read More with a Black Rubber Tyre on a Cast Iron Centre Wheel and Ball Bearings. Load Capacity = 615kg using manual propulsion at 4km/h.Key Specifications:- Top Plate Dimensions: 149x110mm
- Fixing Bolt Hole Centres: 120x60mm (for 12mm Bolts) / 105x75/80mm (for 10mm Bolts)
- Fixing Bolt Hole Size: 13mm
- Overall Height: 303mm
- Castor Offset: 70mm
- Wheel Tread Hardness: 75 +/-3 Shore A
- In Stock
Jacking Castor, 200mm, Cast Iron Wheel, Roller Bearing, 1090kg (JA8CIB)
Original price was: £558.32.£436.90Current price is: £436.90.Sale!200mm Jacking Castor (Genuine Flexello) has 76mm l... Read Moreift with 114.3mm x 63.5mm Hole Centres. The solid cast iron wheel is fitted with a Roller Bearing. Load Capacity = 1090kg.It is important to note that the minimum Jacking Castor load capacity is obtained by calculating the total weight to be carried (unladen unit weight + maximum load) and dividing that by 2. This is because the operation of Jacking Castors means that each castor can be subjected to half the total weight.Most applications require 4 Jacking Castors and in this situation, the recommended total maximum load that can be carried by 4 Jacking Castors is 2,180kg. - In Stock
Jacking Castor, 150mm, Polyurethane Tyre / Cast Iron Centre Wheel, Roller Bearing, 700kg (KJD150SUB)
£303.81150mm Jacking Castor with 75mm lift and 114.3mm... Read More x 63.5mm Hole Centres. The cast iron wheel centre has a Polyurethane Tyre and fitted with a Roller Bearing. Load Capacity = 700kg.
It is important to note that the minimum Jacking Castor load capacity is obtained by calculating the total weight to be carried (unladen unit weight + maximum load) and dividing that by 2. This is because the operation of Jacking Castors means that each castor can be subjected to half the total weight.
Most applications require 4 Jacking Castors and in this situation, the recommended total maximum load that can be carried by 4 Jacking Castors is 1,400kg.
- In Stock
260mm Swivel Castor with Brake, 150kg Capacity | Pneumatic Wheel, Roller Bearing (KS260APNBBR)
£98.04260mm Pneumatic Top Plate Swivel Castor with Brake... Read More (Pressed Steel) with 150x115mm Fixing Bolt Hole Centres. Pneumatic Tyre Wheel on a Metal Centre with a Roller Bearing. Load Capacity = 150kgThe wheel is sized 3.00-8 with a 2 ply tyre thickness making it a strong Light-Medium duty wheel and though it has a 10" diameter, it is also commonly referred to as a 260mm wheel. - In Stock
125mm Stainless Steel Swivel Castor With Brake, 150kg Capacity | Nylon Wheel, Plain Bore (MSS125NYBHBR)
£35.24125mm Bolt Hole Swivel Castor With Brake (Stainles... Read Mores Steel Castor) with 12mm Bolt Hole. Nylon Wheel with Plain Bore. Load Capacity = 150kg - In Stock
100mm Shock Absorbing Swivel Castor With Brake, 100kg Capacity | Polyurethane Tyre Wheel, Ball bearing (GDS100B75SF)
£89.59... Read Moreriant-east-asian: normal; font-size: 14px;">100mm Shock Absorbing Swivel Castor with Brake, Polurethane tyre on Aluminium Centre c/w precision ball bearings, Load Capacity = 100kg. Overall height without load = 160mm. Overall height reduces incrementally by up to 20mm as load increases (see image 2 - GDS100 Curve) and fully compressed with a load of 75kg. - In Stock
150mm AGV Swivel Castor ,Twin Wheel, 630kg Load | Polyurethane Wheel, Ball bearing (GATD150ASFHUD)
Original price was: £288.88.£280.22Current price is: £280.22.Sale!This Twin wheel ... Read More150mm Automated Guided Vehicle (AGV) Castor has a bracket made from strong Forged steel that is zinc plated. There is a hardened Taper Roller Bearing in he swivel head, which has a grease nipple, for smooth swivelling action and durability. The Top Plate is 145mm x 145mm and has 4 bolt holes that are spaced 120mm x 120mm, each with a 11mm hole diameter.The castor is able to tilt +/- 5o from its central axis according to the flatness of the floor. This ensures that this castor's wheels keep contact with the floor allowing smooth AGV movement and protection of the loaded cargo when changing directions (See illustration below)The wheels are more widely separated from each other than most Twin Wheel Castors. When changing direction, the two wheels spin in opposite directions to each other which reduces the castor offset. The smaller the offset the less chance that the AGV will deviate from its designated line.This castor frame has two wheels with a Polyurethane tyre (Shore A 95) on an Aluminium centre each containing ball bearings, The polyurethane wheel has excellent elasticity the minimises slipping that can happen when an AGV starts or stops. In addition, the elasticity also absorbs small shocks arising from small imperfections in the floor. The wheel itself is non marking and will not damage the floor.
